Precision 5A02-H112 Aluminum Spinning Assemblies

Precision Metal Spinning | 5A02-H112 Aluminum Alloy Assembly with Micron-Level Accuracy to GB/T 1804-m, One-Piece Forming for Complex Geometries

Attributes

Material5A02-H112 Aluminum-Magnesium Alloy
Thickness2mm
CoatingPolishing
SizeØ815×230
ApplicationAerospace Skin Panels / Structural Shell Components
Forming ProcessShear Spinning (Thinning) + Power Spinning (Flow Forming)
Structure TypeSeamless / Near-Seamless Integrated Forming
Dimensional Tolerance±0.1 mm
Geometric ToleranceGB/T 1184-K
Linear Tolerance StandardGB/T 1804-m
Surface FinishMirror-Level Deburring
Internal CleanlinessChip-Free / Residue-Free

Core Process

Manufactured using shear spinning (thinning spinning) and power spinning (flow forming), this component addresses the challenges of forming complex curved geometries.

The process enables seamless or near-seamless integrated forming, significantly reducing or eliminating welding requirements while improving structural integrity and consistency.

Precision Control

Dimensional accuracy is controlled in strict accordance with:

GB/T 1804-m for linear tolerances

GB/T 1184-K for geometric tolerances

All critical mating surfaces undergo 100% inspection, with dimensional variation maintained within ±0.1mm to ensure precise assembly fit and performance reliability.

Surface Treatment

A mirror-grade deburring and surface finishing process is applied to achieve a smooth, defect-free surface.

Internal cavities are completely free of metal chips and residues

External surfaces exhibit a mirror-like finish with no visible tool marks

This level of surface quality is critical for preventing electric field concentration in sensitive applications.

Material Adaptability

Specialized in 5A02-H112 aluminum-magnesium alloy spinning, offering excellent corrosion resistance and structural stability.

The material and process combination ensures long-term durability and reliable performance under harsh outdoor environmental conditions.

Technical Specifications

Parameter	Specification
Product Name	Precision Metal Spinning 5A02-H112 Aluminum Alloy Assembly
Material	5A02-H112 Aluminum-Magnesium Alloy
Application	Aerospace Skin Panels / Structural Shell Components
Forming Process	Shear Spinning (Thinning Spinning) + Power Spinning (Flow Forming)
Structure Type	Seamless / Near-Seamless Integrated Forming
Core Manufacturing Capability	Complex Curved Geometry Forming
Linear Tolerance Standard	GB/T 1804-m
Geometric Tolerance Standard	GB/T 1184-K
Dimensional Tolerance	±0.1 mm
Inspection Method	100% Inspection of Critical Mating Surfaces
Surface Treatment	Mirror-Level Deburring & Surface Finishing
Surface Quality	Mirror-Like Finish / No Visible Tool Marks
Internal Cleanliness	Chip-Free / Residue-Free
Structural Advantages	Reduced or Eliminated Welding Requirement
Key Material Characteristics	Excellent Corrosion Resistance & Structural Stability
Key Advantages	High Structural Integrity, Precision Assembly Fit, Stable Outdoor Performance
Typical Application	Aerospace Structural Shells & Precision Aluminum Alloy Assemblies
