180L Large Capacity Chemical & Food Grade Tanks

180L Large-Volume Metal Spinning Container | 5052 Aluminum & 304 Stainless Steel with Rolled Rim and Mirror Finish

Attributes

Material5052 Aluminum / SUS304 Stainless Steel
Thickness2mm
CoatingElectropolishing (Stainless Steel) / Clean Finish (Aluminum)
SizeØ517×H218
ApplicationFood Processing / Chemical Storage
Forming ProcessMulti-Pass Power Spinning (Flow Forming) + Shear Spinning
Capacity180 Liters
DiameterØ500 mm+
Edge StructureRolled Rim (Curling Edge)
Surface FinishElectropolishing (Stainless Steel) / Clean Finish (Aluminum)
Surface Roughness (SS)Ra ≤ 0.4 μm
Dimensional Tolerance±0.5 mm (Diameter) / ±1 mm (Height)

Core Process

Manufactured using multi-pass power spinning (flow forming) combined with shear spinning (thinning), this container is engineered for large-volume deep cylindrical geometries (180L capacity).

For large diameters exceeding Ø500 mm, the process is optimized to address material flow instability during forming.

This ensures uniform wall thickness distribution and eliminates common defects such as uneven bulging or localized deformation.

The rolled rim (curling edge) enhances structural rigidity, handling safety, and edge durability.

Precision Control

For large-scale cylindrical components, dimensional tolerances are controlled as follows:

Diameter Tolerance: ±0.5 mm
Height Tolerance: ±1 mm

Wall thickness is strictly controlled to ensure uniform load-bearing performance, preventing deformation caused by localized thinning.

Surface Treatment

For SUS304 stainless steel:

Internal surface treated by electropolishing (mirror finish)
Surface roughness: Ra ≤ 0.4 μm
Smooth, dead-zone-free surface to prevent material residue buildup

For 5052 aluminum alloy:

Surface free from flow lines, scratches, and forming marks
Clean and uniform finish suitable for food-grade applications

Material Adaptability

5052 Aluminum Alloy: Lightweight (~22 kg), suitable for food ingredient storage

SUS304 Stainless Steel: Excellent resistance to acidic and alkaline corrosion, ideal for chemical storage

Both materials ensure hygienic performance, structural durability, and long-term operational reliability.

Technical Specifications

Parameter	Specification
Product Name	180L Large-Volume Metal Spinning Container
Material Options	5052 Aluminum Alloy / SUS304 Stainless Steel
Application	Food Processing / Chemical Storage
Forming Process	Multi-Pass Power Spinning (Flow Forming) + Shear Spinning (Thinning)
Container Capacity	180 Liters
Structure Type	Deep Cylindrical Spun Container
Diameter	Ø500 mm+
Edge Structure	Rolled Rim (Curling Edge)
Diameter Tolerance	±0.5 mm
Height Tolerance	±1 mm
Wall Thickness Control	Uniform Thickness Distribution
Surface Treatment (SUS304)	Electropolishing (Mirror Finish)
Surface Treatment (5052 Aluminum)	Clean Surface Finish
Surface Roughness (SUS304)	Ra ≤ 0.4 μm
Surface Quality	No Flow Lines, Scratches, or Forming Marks
Internal Surface Requirement	Smooth, Dead-Zone-Free Interior
Structural Advantages	Enhanced Rigidity, Edge Durability, and Load-Bearing Stability
Key Material Characteristics	Corrosion Resistance / Lightweight Structure / Hygienic Performance
Weight (5052 Aluminum Version)	Approx. 22 kg
Defect Control	Prevents Uneven Bulging & Localized Deformation
Typical Applications	Food Ingredient Storage / Chemical Liquid Storage
